Hot Finish Rectangular Hollow Section

Our Product

HOLLOW SECTION

Products

Hot Finish EN10210 S355J2H Rectangular Box Sections, Hot Rolled S355J2H Mild Steel Rectangular Hollow Section Exporters, S355J2H CS Hot Finished Rectangular Pipes Distributors, BS EN 10210 S355J2H Hot Finish RHS Tubes in Mumbai, India.

Hot Finish EN 10210 S355J2H RHS Pipe, Carbon Steel S355J2H Hot Finish Rectangular Hollow Section Suppliers in Mumbai, EN10210 S355J2H MS Hot Finished Rectangular Tube Stockists in India.

Ranflex Metals is one of the best Manufacturer, Stockiest, Supplier, and exporter of Hot Finished S355J2H Mild Steel Rectangular Hollow Sections. This BS EN 10210 S355J2H Hot Finished RHS Tubes contains manganese content up to 1.60%, silicon & carbon 0.55%, and 0.22% respectively, and phosphorus and sulfur 0.030%. It also includes some portion of molybdenum content. The wall thickness of EN 10210 S355J2H Seamless Hot Finished Rectangular Hollow Section Tubing ranges from 0.5mm to 25mm and its 6000mm to 14000mm. Customers can grab these pipes as per their specifications.

Usually, Hot Finished EN 10210 S355J2H Rectangular Hollow Section is used between the temperature range of 500 Degree C to 800 Degree C and In continuous service, It can be used up to 899 Degree C. it can be used effectively at high elevated temperature. These Rectangular Hollow Sections are less resistant to air and water. Hot Finished EN 10210 S355J2H Rectangular Box Sections possesses high mechanical strength, and high tensile and yield strength. It possesses the best welding properties. These S355J2H Hot Finished Welded Structural Rectangular Hollow Sections are highly durable and are available at the most affordable price. This cannot be hardened further by the heat working process.

Hot Finished EN 10210 S355J2H Rectangular Hollow Section ERW Pipes are mostly used in the construction industry. It is mostly used in the construction of buildings, dams, etc. Hot Finished EN 10210 S355J2H Rectangular Hollow Section Rectangular Pipes are widely used in the marine industry and offshore oil drilling companies. It is also mostly used in the architecture industry.

Hot Finish EN 10210 S355J2H RHS Specification

Standard	BS EN 10210 - Hot finished structural hollow sections of non-alloy and fine grain steels
Grade	S355J2H
Sizes	10mm x 15mm --- 150mmx50mm --- 300mmx400mm --- 600mmx550mm
Wall Thickness	0.5mm - 25mm
Length	6000-14000 mm
Type	Seamless/ Welded / ERW
Dimensional Tolerances	Thickness (All sizes +/- 10%)
Packing	In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection	Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized

Hot Finish EN 10210 S355J2H RHS Properties

Steel Grade		% by mass maximum
Steel Name	Steel Number	C specified thickness (mm)		Si	Mn	P	S	N
		<_40	> 40 <_ 120
S355J2H	1.0576	0.22	0.22	0.55	1.60	0.030	0.030	-

Steel Grade		Minimum yield strength eH Mpa						Minimum tensile strength Rm Mpa
Steel Name	Steel Number	Specified thickness in mm						Specified thickness in mm
Steel Name	Steel Number	<_16	>16 <_40	>40 <_63	>63 <_ 80	>80 <_100	>100 <_120	<_3	>3 <_100	>100 <_ 120
S355J2H	1.0576	355	345	335	325	315	295	510-680	470-630	450-600

HxB – Height x Base

Wt – Wall thickness

Kg/m – Kilos per linear metre

Er – External radius

L – Standard bar length

Size mm	kg/m	Size mm	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192

Hot Finish EN 10210 S355J2H RHS Services

Packaging

We Hollow Section Ensure the best quality of Packing , because its play important role especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put extraordinary concern regarding packaging.

Testings (Destructive, Non Destructive)

Application Industries
