EN 10210 Hot Finish S275J0H ERW SHS Pipes Dealers in India, EN 10210 S275J0H Seamless Hot Finish Square Hollow Section Tubing, EN 10210 S275J0H Hot Finished Welded Structural Square Hollow Sections.

Carbon Steel S275J0H Hot Finish Square Hollow Section Suppliers in Mumbai, EN10210 S275J0H MS Hot Finished Square Tube Stockists in India, Hot Finish EN 10210 S275J0H SHS Pipe.

Hot Rolled S275J0H Mild Steel Square Hollow Section Exporters, BS EN 10210 S275J0H Hot Finish SHS Tubes, S275J0H CS Hot Finish Square Pipes Distributors, Hot Finished EN10210 S275J0H Square Box Sections in Mumbai, India.

Get A Qoute

Ranflex Metals is one of the best manufacturers, seller, exporter, and stockiest of Hot Finished EN 10210 S275J0H Square Hollow Section. At Ranflex Metals, these Hot Finished EN 10210 S275J0H Square Hollow Sections are made using good quality raw material and the best technology. EN 10210 Hot Finished S275J0H ERW Square Hollow Section Pipe has the best corrosion resistance to pitting and crevice corrosion. The length of these Hot Finished EN 10210 S275J0H Square Hollow Section is from 6000mm to 14000mm, and its size ranges from 20mm*20mm to 400mm*400mm.

Hot Finished EN 10210 S275JOH Square Hollow Section provides the excellent corrosion resistance to oxidation corrosion up to 1598 Degree F, whereas, it continuous service it gives corrosion resistance up to 1697 Degree F. Hot Finished EN 10210 S275J0H Square Hollow Section ERW Pipes offers high tensile strength and best welding properties. At Ranflex Metals, We always emphasized that our EN 10210 S275J0H MS Hot Finished Square Tubes are being manufactured following international quality standards. It has the best mechanical properties. These Grade S2750H Hot Finished Welded Structural Square Hollow Section has an accurate rugged design and higher durability. It contains manganese content up to 1.6%, and some portion of carbon, silicon, phosphorus, and sulfur content.

Hot Finished EN 10210 S275J0H Square Hollow Section Seamless Pipes are mostly used in the oil & gas processing units. It is also used in the pulp and paper industry. Hot Finished EN 10210 S275J0H Square Box Sections are usually used in the marine industry and offshore oil drilling companies. It is widely used in the chemical industry and the petrochemical industry. Grade S2750H Hot Finished Welded Structural Square Hollow Section is used extensively in the petroleum industry.

Hot Finish EN 10210 S275J0H SHS Specification

Standard	BS EN 10210 - Hot finished structural hollow sections of non-alloy and fine grain steels
Grade	S275J0H
SHS (Square Hollow Sections) Sizes	2020mm-400400mm
Wall Thickness	0.5mm - 25mm
Length	6000-14000 mm
Type	Seamless/ Welded / ERW
Dimensional Tolerances	Thickness (All sizes +/- 10%)
Packing	In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection	Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized

Hot Finish EN 10210 S235JRH SHS Properties

Steel Grade		% by mass maximum
Steel Name	Steel Number	C specified thickness (mm)		Si	Mn	P	S	N
		<_40	> 40 <_ 120
S275J0H	1.0149	0.20	0.22	-	1.50	0.035	0.035	0.009

Steel Grade		Minimum yield strength eH Mpa						Minimum tensile strength Rm Mpa
Steel Name	Steel Number	Specified thickness in mm						Specified thickness in mm
Steel Name	Steel Number	<_16	>16 <_40	>40 <_63	>63 <_ 80	>80 <_100	>100 <_120	<_3	>3 <_100	>100 <_ 120
S275J0H	1.0149	275	265	255	245	235	225	430-580	410-560	400-540

HxB – Height x Base

Wt – Wall thickness

Kg/m – Kilos per linear metre

Er – External radius

L – Standard bar length

Size mm	kg/m	Size mm	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192

Hot Finish EN 10210 S275J0H SHS Services
