ASTM A500 Gr B Seamless Hot Finished Square Hollow Section Tube, A500 Gr B Hot Finish ERW SHS Pipes Dealers in India, ASTM A500 Gr B Hot Finish Welded Structural Square Tubing.

ASTM A500 Gr B Carbon Steel Square Hollow Section Suppliers in Mumbai, ASTM A500 Grade B Hot Finish MS Square Tube Stockists in India, Hot Rolled ASTM A500 Gr B SHS Pipe.

ASTM A500 Gr. B CS Hot Finish Square Pipes Distributors, ASME SA500 Gr B Hot Finished SHS Tubing, ASTM A500 Gr B Hot Finish Mild Steel Square Hollow Section Exporters, Hot Finish ASTM A500 Gr B Square Box Sections in Mumbai, India.

Get A Qoute

The A500 Gr B Hot Finished ERW Square Hollow Section is mostly used at extreme heat temperature. This grade is highly resistant to fire. It possesses good weldability and fabrication properties. Hot Finished ASTM A500 GR B Square Hollow Section contains chromium, carbon, copper, and nitrogen content. At Ranflex Metals, these Hot Finished ASTM A500 Gr B Square Box Sections are made using new technology and by high skilled experts. It is produced following guidance of the International standards of quality. It is mostly used in fire related work as it possess high fire resistance properties. It also possesses good corrosion resistance properties.

The Hot Finished ASTM A500 Gr B Square Hollow Section Welded Pipes is very often used in marine industry. It is also used in dairy equipment For example: It is used in milking machines & equipment, containers, valves, milk trucks, and in tanks and railroad cars. Hot Finished ASTM A500 Gr B Square Hollow Section can be used extensively in constructional works, such as in construction of building and bridges. It can also be used extensively at increasing temperatures.

This Gr B ASTM A500 Carbon Steel Hot Finished Square Pipes usually passes through heat treatment process during its production. Once, it is manufactured, it went through certain tests such as quality test, flattering test, and material tests. This ASTM A500 Grade B Hot Finished Mild Steel Square Tube are available in many sizes and shapes at the most econoimc cost.

ASTM A500 Gr B Square Hot Finish Hollow Section Specification

Standard Specification	ASTM A500 Hot Finish Welded and Seamless Carbon Steel Structural Square Tubing
Grade	ASTM A500 Grade B
SHS (Square Hollow Sections) Sizes	2020mm-400400mm
Wall Thickness	0.5mm - 25mm
Length	6000-14000 mm
Type	Seamless/ Welded / ERW
Dimensional Tolerances	Thickness (All sizes +/- 10%)
Packing	In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection	Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized

ASTM A500 Gr B Hot Finish Square Hollow Section Properties

ASTM A500	C, max	P, max	S, max	Cu, min
Grade B	0.26	0.035	0.035	0.20

ASTM A500	Tensile strength, min	Yield strength, min,	Elongation in 2 in. (50.8 mm) min, %
Grade B	400 MPa, 58 000 psi	317 MPa, 46 000 psi	23

HxB – Height x Base

Wt – Wall thickness

Kg/m – Kilos per linear metre

Er – External radius

L – Standard bar length

Size mm	kg/m	Size mm	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192
